Operating weight with cab
|
21500 kg
|
|
Engine power
|
112 kW (150 hp) @ 1950 rpm-124 kW (166 hp) @ 2050 rpm
|
|
Bucket capacity
|
0.9/0.95/1.0/1.2 m³
|
|
Maximum travel speed (High
|
5.3/5.7/4.9 km/h
|
|
Maximum travel speed (Low
|
3.0/3.3/2.9 km/h
|
|
Maximum swing speed
|
10.5/12.5/12 rpm
|
|
Arm breakout force
|
97 kN
|
|
Arm breakout force Power boost
|
105 kN
|
|
Bucket breakout force
|
140 kN
|
|
Bucket breakout force Power boost
|
152.5 kN
|
|
Shipping length
|
9570/9540 mm
|
|
Shipping width
|
2800 mm
|
|
Shipping height
|
3140 mm
|
|
Track shoe width (std)
|
600 mm
|
|
Boom
|
5710 mm
|
|
Arm
|
2915 mm
|
|
Digging reach
|
9870 mm
|
|
Digging reach on ground
|
9685 mm
|
|
Digging depth
|
6562 mm
|
|
Vertical wall digging depth
|
5080 mm
|
|
Cutting height
|
9945 mm
|
|
Dumping height
|
7170 mm
|
|
Minimum front swing radius
|
3090 mm
|
|
Model
|
Cummins
|
|
Emission
|
EPA Tier 2 / Tier 3 / EU Stage II / Stage IIIA
|
|
System maximum flow
|
2×224 L/min ( 2x59 gal/min)
|
|
System pressure
|
34.3 MPa
|
