Operating weight
|
16700 kg
|
|
Standard bucket
|
3 m³
|
|
Gross power
|
162 kW (220 hp) @ 2200 rpm
|
|
Net power
|
148 kW (201 hp) @ 2200 rpm
|
|
Rated load
|
5000 kg
|
|
Total cycle time
|
11.5 s
|
|
Tipping load-full turn
|
11000 kg
|
|
Bucket breakout force
|
167 kN
|
|
Dump clearance, full height discharge
|
2970 mm
|
|
Dump reach, full height discharge
|
1200 mm
|
|
Model
|
6LT9.3
|
|
Emissions
|
EPA Tier 2 / EU Stage II
|
|
Cooling system
|
Charge air cooling
|
|
Length with bucket down
|
7598 mm
|
|
Width over tires
|
2976 mm
|
|
Cab height
|
3480 mm
|
|
Turning radius, outside of tire
|
6647 mm
|
|
Bucket capacity
|
1.8-5.6 m³
|
|
General Purpose
|
3 m³
|
|
Light material
|
3.0, 4.5, 5.0, 5.6 m³
|
|
Heavy-rock
|
2.7 m³
|
