Max. operating mass 14000 kg
Mass with max. ballast 30000 kg
Speed low 7 km/h
Speed high 18 km/h
Theor. gradeability %
Rolling width 2370 mm
Tyre overlap 52 mm
Wheel loads, without ballast 1556 kg
Wheel loads, with max. ballast 3333 kg
Tyre pressure, min 380 kPa
Tyre pressure, max 780 kPa
Tyre type (smooth) 13/80-20
Water spray system, type Pressurized
Water spray system, tank capacity 600 l 600 l
Water spray system, spray nozzle One per tyre
Ballast mass 16000 kg
Manufacturer/Model Cummins 4BTAA3.9-C125
Rated power, SAE J1995 93 kW (125 hp ) @ 2200 rpm
Type Turbocharged and Charge Air Cooled
Fuel tank capacity 320 l
Electrical system 24 V
Driving Axial piston pump with variable displacement.
Axial piston motor with variable displacement.
Steering Gear pump with constant displacement.
Service brake Drum brakes.
Parking/Emergency brake Failsafe multidisc brakes in gear box
