Max. rated lifting capacity
|
30 t
|
|
Max. rated lifting torque of basic boom
|
1040 kN·m
|
|
Max. rated lifting torque of full extended
|
596 kN·m
|
|
Max. lifting height of Jib
|
34+8.7 m
|
|
Overall net weight
|
30000 kg
|
|
Max. single rope speed
|
130 m/min
|
|
Time of telescoping boom
|
55 s
|
|
Time of elevating boom
|
35
|
|
Max. slewing speed
|
2.4 rpm
|
|
Max. travel speed
|
80 km/h
|
|
Gradeability
|
40%
|
|
Min. turning diameter
|
≤24 m
|
|
Dimensions (L x W x H)
|
12790x2600x3400 mm
|
|
Outrigger longitudinal span
|
5430 mm
|
|
Outrigger transverse span
|
6400 mm
|
|
Sections of boom
|
4
|
|
Length of main boom
|
34 m
|
|
Length of jib
|
8.8 m
|
|
Engine Model
|
ISDe 285 30
|
|
Rated power
|
210 kW
|
|
Max. rated torque
|
970 N·m
|
